How To Adjust An uPVC Window?

Adjusting an uPVC window is a straightforward task that can improve the window's performance and extend its lifespan. Proper adjustment ensures that the window opens and closes smoothly, seals correctly, and maintains energy efficiency. This guide will walk you through the steps required to adjust your uPVC window.

Understanding uPVC Windows

Before diving into the adjustment process, it’s essential to understand the components of a uPVC window. A typical uPVC window includes the following parts:

• Frame: The outer structure that holds the window in place.
• Sash: The part of the window that moves (opens and closes).
• Hinges: Located on one side of the sash, allowing it to pivot.
• Locking Mechanism: Ensures the window stays shut when closed.
• Gaskets: Rubber seals around the sash that provide an airtight seal.

Tools You Will Need

To adjust a uPVC window, you will need the following tools:

• Allen keys (usually 4mm or 5mm)
• Phillips screwdriver
• Flathead screwdriver
• Lubricant spray (such as WD-40)

Step-By-Step Guide To Adjusting a uPVC Window

1. Inspect The Window

Before making any adjustments, inspect the window to identify any issues. Look for signs of drafts, difficulty in opening or closing, or misalignment. Common problems that indicate the need for adjustment include:

• Draughts: Indicate that the window isn’t sealing properly.
• Stiffness: Difficulty in opening or closing the window.
• Misalignment: The sash appears skewed or doesn’t sit flush with the frame.

2. Adjust The Hinges

Side-to-Side Adjustment:

• Open the window fully to access the hinges.
• Locate the adjustment screw on the hinge. This is typically a hexagonal screw that can be adjusted using an Allen key.
• Insert the Allen key and turn it to move the sash horizontally. Turning the screw clockwise usually moves the sash towards the hinge, while turning it counterclockwise moves it away from the hinge.
• Adjust until the sash is centred within the frame.

Height Adjustment:

• Some uPVC windows have a height adjustment screw located on the bottom hinge.
• To adjust the height, turn the screw clockwise to raise the sash and counterclockwise to lower it.
• Ensure the sash is level with the frame after making adjustments.

Compression Adjustment:

• Compression adjustment affects how tightly the sash fits against the frame when closed.
• Locate the compression adjustment screw on the hinge.
• Turning the screw clockwise will pull the sash closer to the frame, enhancing the seal. Turning it counterclockwise will loosen the seal.
• Adjust until the window closes firmly but can still be operated smoothly.

3. Adjust The Locking Mechanism

Cam Adjustments:

• uPVC windows often have cam locks (mushroom-shaped bolts) that engage with keeps (metal plates) on the frame.
• To adjust, locate the cams around the perimeter of the sash.
• Using an Allen key, rotate the cams. Turning them clockwise will draw the sash closer to the frame, increasing the seal. Counterclockwise will loosen the seal.
• Ensure that all cams are adjusted evenly to maintain an even seal around the window.

4. Lubricate Moving Parts

• Over time, the moving parts of a uPVC window can become stiff. Lubricating these parts can improve functionality.
• Spray a light lubricant, such as WD-40, onto the hinges, locking mechanism, and any other moving parts.
• Open and close the window several times to distribute the lubricant and ensure smooth operation.

5. Check And Replace Gaskets

• Gaskets provide an airtight seal and can degrade over time.
• Inspect the gaskets around the sash for signs of wear or damage.
• If the gaskets are worn out, replace them with new ones. Remove the old gasket by pulling it out and pressing the new gasket into the groove.

6. Final Checks

• After making all adjustments, close the window and check for any remaining drafts or operational issues.
• Ensure that the sash sits flush with the frame and that the window locks securely.
• Test the window several times to confirm that it opens and closes smoothly without any sticking or misalignment.

Tips For Maintaining uPVC Windows

• Regular Cleaning: Clean the window frames and glass regularly to prevent dirt and grime build-up.
• Periodic Lubrication: Lubricate the moving parts periodically to maintain smooth operation.
• Inspection: Regularly inspect the windows for any signs of wear or damage and address issues promptly.
