Home Security 4CH Wireless IP Cameras NVR Kit
![Image](https://www.apsense.com/blog_photo/20170509/1494318075321877.jpg)
Wireless Home Security System 4CH WIFI NVR with 11 Inch HD LCD Screen, WIFI NVR Wireless CCTV IP Camera H.264
Key Features
• 1080P/960P/720P Wireless Network Video Recorde
• Built-in WIFI module with high-performance and high stability
• Free Cloud Service, easy to achieve a variety of network
• Automatically Connection between NVR and IPC
• Support video preview/recording/playback/backup
• Support the mixed use of wireless and wire, support different scene
• Support Android/IOS/PC remote
• Mobile surveillance supported,Including iPhone, iPad, Android
• 1HDD Max 4TB per HDD
Specification
Model NO. | DR-W7604D | |||
System | ||||
Operating system | embedded Linux | |||
System resources | Simultaneously multi-channel real-time recording, playback, network operation, USB backup | |||
Video | ||||
Decode | H.264(High Profile) | |||
Monitor quality | VGA, HDMI: HD | |||
Video input | D1/960H/720P/960P/1080P | |||
HDMI Output | 1CH, Resolution: 1024x768, 1280x1024, 1366x768, 1440x900, 1920x1080 | |||
VGA Output | 1CH, Resolution: 1024x768, 1280x1024, 1366x768, 1440x900, 1920x1080 | |||
Playback quality | 4CH | |||
Encode ability | 4*1080P | |||
Multi-mode input | Network: 4*1080P; 4*720P | |||
Audio | ||||
Audio interface | 3.5mm headphone jack(Optional) | |||
Record & Playback | ||||
Record mode | manual>alarm>motion detection>timing | |||
Local Playback | 4CH(local input mode) | |||
Search mode | Search by time, calendar, event, channel | |||
Storage & backup | ||||
Storage | 1 SATA | |||
Video storage | 4TB for each HDD | |||
External Interface | ||||
Audio interface | 3.5mm headphone jack(Optional) | |||
Video output | 1CH VGA, 1CH HDMI | |||
Network interface | 1 RJ45 10M/100M self-adaption, 2 WIFI connector | |||
PTZ control | - | |||
USB | 2* USB 2.0 ports | |||
HDD | 1*SATA ports | |||
ELECTRICAL | ||||
Power Consumption | <15W (without HDD) | |||
Adapter Requirement | DC12V 3A | |||
General | ||||
Working Temperature | -10℃ ~ +50℃ | |||
Storage Temperature | 0℃ ~ +55℃ | |||
Working Humidity | Less than 90% (no condensation) | |||
Working Environment | 86kpa—106kpa | |||
Dimensions | 300*228*48mm | |||
Net Weight | 1.75kg | |||
Gross Weight | 2.50kg |
